| PARAMETERS | MIN | TYP | MAX | UNITS | NOTES |
|---|---|---|---|---|---|
| Accuracy (RSS of linearity,hysteresis, and repeatability) | -0.3 -0.15 |
±0.5 ±0.1 |
0.3 0.15 |
%F.S. BFSL | |
| Isolation, Body to any Lead | 100 | MΩ | @250VDC | ||
| Pressure Cycles | 1X107 | 0~FS Cycles | |||
| Proof Pressure | 2X | Rated | |||
| Burst Pressure | 3X | Rated | |||
| Long Term Stability (1 year) | ±0.25 | %F.S | |||
| Total Error Band | -1.00 | ±1 | 1.00 | %F.S | Over compensated temperature range |
| Compensated Temperature | 0 | 70 | °C | ||
| Operating Temperature | -10 | 120 | °C | ||
| Storage Temperature | -55 | +150 | °C | ||
| Load Resistance (RL) | RL > 100k | Ω | Voltage Output | ||
| Load Resistance (RL) | < (Supply Voltage-9V) / 0.02A | Ω | Current Output | ||
| Current Consumption | 10 | mA | Voltage Output | ||
| Rise Time (10% to 90%) | <1ms (Voltage Output); <2ms (Current Output) | ||||
| Pressure Port Material | 316L & Carpenter SUS 17-4PH | ||||
| Shock | 50g, 11msec Half Sine Shock per MIL-STD-202G, Method 213B, Condition A | ||||
| Vibration | ±20g, MIL-STD-810C, Procedure 514.2-2, Curve L | ||||
